A CSS-driven progress ring in Angular

A standalone Angular component draws an SVG progress ring by pushing computed geometry into CSS custom properties via host bindings.

Explained by highlit
Angular Intermediate host-bindings css-custom-properties input-setters svg accessibility
1import { Component, HostBinding, Input } from '@angular/core';
2
3type ProgressVariant = 'success' | 'warning' | 'danger';
4
5@Component({
6 selector: 'app-progress-ring',
7 standalone: true,
8 template: `
9 <svg viewBox="0 0 120 120">
10 <circle class="track" cx="60" cy="60" r="54" />
11 <circle class="indicator" cx="60" cy="60" r="54" />
12 </svg>
13 <span class="label">{{ value }}%</span>
14 `,
15 styleUrl: './progress-ring.component.css',
16})
17export class ProgressRingComponent {
18 private readonly circumference = 2 * Math.PI * 54;
19
20 @Input() variant: ProgressVariant = 'success';
21
22 @Input({ required: true })
23 set value(percent: number) {
24 this._value = Math.min(100, Math.max(0, percent));
25 }
26 get value(): number {
27 return this._value;
28 }
29 private _value = 0;
30
31 @HostBinding('style.--ring-circumference')
32 get circumferenceVar(): string {
33 return `${this.circumference}px`;
34 }
35
36 @HostBinding('style.--ring-offset')
37 get offsetVar(): string {
38 return `${this.circumference * (1 - this.value / 100)}px`;
39 }
40
41 @HostBinding('style.--ring-color')
42 get colorVar(): string {
43 return `var(--tone-${this.variant})`;
44 }
45
46 @HostBinding('attr.role') readonly role = 'progressbar';
47
48 @HostBinding('attr.aria-valuenow')
49 get ariaValue(): number {
50 return this.value;
51 }
52}
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1Host bindings that return computed CSS custom properties let the browser handle rendering while the component owns the math.
  2. 2A setter on an @Input is the natural place to validate and clamp incoming values before they reach the view.
  3. 3Mirroring visual state into ARIA attributes keeps a custom control accessible to assistive technology.
