A custom preloading strategy in Angular
Control which lazy-loaded route modules preload — and when — using route data flags and a delay.
Explained by
highlit
1import { Injectable } from '@angular/core';
2import { PreloadingStrategy, Route, Routes, RouterModule } from '@angular/router';
3import { NgModule } from '@angular/core';
4import { Observable, of, timer } from 'rxjs';
5import { mergeMap } from 'rxjs/operators';
6
7@Injectable({ providedIn: 'root' })
8export class SelectivePreloadStrategy implements PreloadingStrategy {
9 preload(route: Route, load: () => Observable<unknown>): Observable<unknown> {
10 if (!route.data?.['preload']) {
11 return of(null);
12 }
13
14 const delay = (route.data['preloadDelay'] as number) ?? 0;
15 return timer(delay).pipe(mergeMap(() => load()));
16 }
17}
18
19const routes: Routes = [
20 {
21 path: 'dashboard',
22 loadChildren: () =>
23 import('./dashboard/dashboard.module').then((m) => m.DashboardModule),
24 data: { preload: true },
25 },
26 {
27 path: 'reports',
28 loadChildren: () =>
29 import('./reports/reports.module').then((m) => m.ReportsModule),
30 data: { preload: true, preloadDelay: 3000 },
31 },
32 {
33 path: 'admin',
34 loadChildren: () =>
35 import('./admin/admin.module').then((m) => m.AdminModule),
36 data: { preload: false },
37 },
38];
39
40@NgModule({
41 imports: [
42 RouterModule.forRoot(routes, {
43 preloadingStrategy: SelectivePreloadStrategy,
44 }),
45 ],
46 exports: [RouterModule],
47})
48export class AppRoutingModule {}
01 / 01
STEP 01
‹ swipe to step through ›
Walkthrough
Space play
←→ step
click any line
Three takeaways
- 1A PreloadingStrategy lets you decide per-route whether a lazy module downloads in the background after the app boots.
- 2Route data is a flexible channel for passing configuration into infrastructure like preloaders.
- 3Returning of(null) from preload cleanly opts a route out without loading its bundle.
