Backing HTTP sessions with Redis in Spring

A Spring config class that stores servlet sessions in Redis, tuning the connection, serialization, and cookie behavior.

Explained by highlit
Spring Intermediate session-management redis distributed-state configuration cookies
1@Configuration
2@EnableRedisHttpSession(namespace = "myapp:sessions", maxInactiveIntervalInSeconds = 1800, flushMode = FlushMode.IMMEDIATE)
3public class SessionConfig {
4
5 @Bean
6 public LettuceConnectionFactory redisConnectionFactory(
7 @Value("${spring.redis.host}") String host,
8 @Value("${spring.redis.port}") int port,
9 @Value("${spring.redis.password:}") String password) {
10
11 RedisStandaloneConfiguration standalone = new RedisStandaloneConfiguration(host, port);
12 if (!password.isBlank()) {
13 standalone.setPassword(RedisPassword.of(password));
14 }
15
16 LettuceClientConfiguration clientConfig = LettuceClientConfiguration.builder()
17 .commandTimeout(Duration.ofSeconds(2))
18 .clientOptions(ClientOptions.builder()
19 .autoReconnect(true)
20 .disconnectedBehavior(ClientOptions.DisconnectedBehavior.REJECT_COMMANDS)
21 .build())
22 .build();
23
24 return new LettuceConnectionFactory(standalone, clientConfig);
25 }
26
27 @Bean
28 public RedisSerializer<Object> springSessionDefaultRedisSerializer() {
29 return new GenericJackson2JsonRedisSerializer();
30 }
31
32 @Bean
33 public CookieSerializer cookieSerializer() {
34 DefaultCookieSerializer serializer = new DefaultCookieSerializer();
35 serializer.setCookieName("MYAPPSESSION");
36 serializer.setCookiePath("/");
37 serializer.setUseHttpOnlyCookie(true);
38 serializer.setSameSite("Lax");
39 serializer.setUseSecureCookie(true);
40 return serializer;
41 }
42
43 @Bean
44 public ConfigureRedisAction configureRedisAction() {
45 return ConfigureRedisAction.NO_OP;
46 }
47}
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1Externalizing HTTP sessions to Redis lets multiple app instances share login state without sticky sessions.
  2. 2Explicit serializer and cookie beans give you control over on-disk format and browser security attributes.
  3. 3Connection options like command timeouts and disconnected behavior decide how the app fails when Redis is unreachable.
