typescript 54 lines · 9 steps

Building a binary-heap priority queue in TypeScript

A generic min-heap that keeps the lowest-priority item ready at the front through bubble-up and bubble-down.

Explained by highlit
Intermediate binary-heap priority-queue generics data-structures algorithms
1export class PriorityQueue<T> {
2 private heap: Array<{ value: T; priority: number }> = [];
3
4 get size(): number {
5 return this.heap.length;
6 }
7
8 peek(): T | undefined {
9 return this.heap[0]?.value;
10 }
11
12 enqueue(value: T, priority: number): void {
13 this.heap.push({ value, priority });
14 this.bubbleUp(this.heap.length - 1);
15 }
16
17 dequeue(): T | undefined {
18 if (this.heap.length === 0) return undefined;
19 const top = this.heap[0];
20 const last = this.heap.pop()!;
21 if (this.heap.length > 0) {
22 this.heap[0] = last;
23 this.bubbleDown(0);
24 }
25 return top.value;
26 }
27
28 private bubbleUp(index: number): void {
29 while (index > 0) {
30 const parent = (index - 1) >> 1;
31 if (this.heap[index].priority >= this.heap[parent].priority) break;
32 this.swap(index, parent);
33 index = parent;
34 }
35 }
36
37 private bubbleDown(index: number): void {
38 const n = this.heap.length;
39 while (true) {
40 const left = index * 2 + 1;
41 const right = left + 1;
42 let smallest = index;
43 if (left < n && this.heap[left].priority < this.heap[smallest].priority) smallest = left;
44 if (right < n && this.heap[right].priority < this.heap[smallest].priority) smallest = right;
45 if (smallest === index) break;
46 this.swap(index, smallest);
47 index = smallest;
48 }
49 }
50
51 private swap(a: number, b: number): void {
52 [this.heap[a], this.heap[b]] = [this.heap[b], this.heap[a]];
53 }
54}
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1A binary heap stores a tree in a flat array, using index arithmetic to find parents and children.
  2. 2Insertion and removal both cost O(log n) because an item only travels the height of the tree.
  3. 3Sifting up on enqueue and down on dequeue is what preserves the heap ordering invariant.
