java 33 lines · 9 steps

Building an order pipeline with Spring Integration

A Spring Integration flow validates, transforms, and reserves orders as messages travel through channels.

Explained by highlit
Spring Intermediate messaging pipeline enterprise integration patterns declarative flows channels
1@Configuration
2@EnableIntegration
3public class OrderProcessingFlow {
4
5 @Bean
6 public MessageChannel incomingOrders() {
7 return MessageChannels.direct().getObject();
8 }
9
10 @Bean
11 public IntegrationFlow orderFlow(OrderValidator validator, InventoryService inventory) {
12 return IntegrationFlow.from(incomingOrders())
13 .filter(Order.class, order -> order.getTotal().signum() > 0,
14 f -> f.discardChannel("rejectedOrders"))
15 .transform(Order.class, validator::normalize)
16 .handle(Order.class, (order, headers) -> {
17 inventory.reserve(order.getSku(), order.getQuantity());
18 return order.withStatus(OrderStatus.RESERVED);
19 })
20 .enrichHeaders(h -> h.header("processedAt", Instant.now().toString()))
21 .channel("confirmedOrders")
22 .get();
23 }
24
25 @Bean
26 public IntegrationFlow confirmationFlow(NotificationGateway gateway) {
27 return IntegrationFlow.from("confirmedOrders")
28 .<Order, String>transform(order ->
29 "Order %s reserved for %s".formatted(order.getId(), order.getCustomer()))
30 .handle(gateway)
31 .get();
32 }
33}
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1Spring Integration models processing as messages moving through composable channels rather than direct method calls.
  2. 2Each stage (filter, transform, handle) has a single responsibility, keeping the pipeline readable and easy to extend.
  3. 3Named channels let independent flows hand work off to each other, decoupling producers from consumers.
