How OIDC login works in Spring Security

A Spring Security config wires up OAuth2/OIDC login and enriches the authenticated user with a custom role based on claims.

Explained by highlit

Spring Intermediate oauth2 openid-connect authorization authentication security-filter-chain

1@Configuration
2@EnableWebSecurity
3public class OAuth2SecurityConfig {
4
  @Bean
  public SecurityFilterChain filterChain(HttpSecurity http) throws Exception {
      http
          .authorizeHttpRequests(auth -> auth
              .requestMatchers("/", "/error", "/webjars/**").permitAll()
              .anyRequest().authenticated()
          )
          .oauth2Login(oauth2 -> oauth2
              .userInfoEndpoint(userInfo -> userInfo
                  .oidcUserService(this.oidcUserService())
              )
              .defaultSuccessUrl("/dashboard", true)
          )
          .logout(logout -> logout
              .logoutSuccessUrl("/")
              .clearAuthentication(true)
          );
      return http.build();
  }
24
  private OAuth2UserService<OidcUserRequest, OidcUser> oidcUserService() {
      OidcUserService delegate = new OidcUserService();
      return userRequest -> {
          OidcUser oidcUser = delegate.loadUser(userRequest);
          String registrationId = userRequest.getClientRegistration().getRegistrationId();
          Set<GrantedAuthority> authorities = new LinkedHashSet<>(oidcUser.getAuthorities());
          if (Boolean.TRUE.equals(oidcUser.getClaimAsBoolean("email_verified"))) {
              authorities.add(new SimpleGrantedAuthority("ROLE_VERIFIED"));
          }
          return new DefaultOidcUser(authorities, oidcUser.getIdToken(), oidcUser.getUserInfo());
      };
  }
37}
38
39@Controller
40class DashboardController {
41
  @GetMapping("/dashboard")
  public String dashboard(@AuthenticationPrincipal OidcUser principal, Model model) {
      model.addAttribute("name", principal.getFullName());
      model.addAttribute("email", principal.getEmail());
      model.addAttribute("picture", principal.getClaimAsString("picture"));
      model.addAttribute("issuer", principal.getIssuer());
      return "dashboard";
  }
50}

01 / 01

STEP 01

Walkthrough

Space play ←→ step click any line

Three takeaways

1A SecurityFilterChain bean is where you declare which routes are public and how login and logout behave.
2Wrapping the default OidcUserService lets you add custom authorities derived from token claims.
3Once login succeeds, the OidcUser can be injected straight into controllers as the authentication principal.
