Interpolating a color gradient in TypeScript

Map a number to a smooth color by linearly blending between fixed RGB stops.

Explained by highlit

Intermediate interpolation data-visualization color type-safety

1type RGB = readonly [number, number, number];
2
3interface ColorStop {
4  offset: number;
5  color: RGB;
6}
7
8const HEATMAP_STOPS: ColorStop[] = [
9  { offset: 0.0, color: [33, 102, 172] },
10  { offset: 0.25, color: [103, 169, 207] },
11  { offset: 0.5, color: [247, 247, 247] },
12  { offset: 0.75, color: [239, 138, 98] },
13  { offset: 1.0, color: [178, 24, 43] },
14];
15
16const clamp01 = (n: number): number => Math.min(1, Math.max(0, n));
17
18const lerp = (a: number, b: number, t: number): number => a + (b - a) * t;
19
20function interpolateGradient(t: number, stops: ColorStop[] = HEATMAP_STOPS): RGB {
21  const clamped = clamp01(t);
22
23  let upper = stops.findIndex((stop) => stop.offset >= clamped);
24  if (upper <= 0) {
25    return upper === 0 ? stops[0].color : stops[stops.length - 1].color;
26  }
27
28  const lower = stops[upper - 1];
29  const next = stops[upper];
30  const span = next.offset - lower.offset;
31  const local = span === 0 ? 0 : (clamped - lower.offset) / span;
32
33  return [
34    Math.round(lerp(lower.color[0], next.color[0], local)),
35    Math.round(lerp(lower.color[1], next.color[1], local)),
36    Math.round(lerp(lower.color[2], next.color[2], local)),
37  ];
38}
39
40export function heatmapCellColor(value: number, min: number, max: number): string {
41  const normalized = max === min ? 0.5 : (value - min) / (max - min);
42  const [r, g, b] = interpolateGradient(normalized);
43  return `rgb(${r}, ${g}, ${b})`;
44}

01 / 01

STEP 01

Walkthrough

Space play ←→ step click any line

Three takeaways

1Linear interpolation between sorted stops turns a scalar into a continuous color scale.
2Clamping and edge-case guards keep out-of-range or degenerate inputs from breaking the math.
3A small readonly tuple type makes the RGB contract explicit and hard to misuse.
