A token-bucket rate limiter in Tokio

A background ticker paces requests through channels so callers acquire permits at a fixed rate per second.

Explained by highlit
Advanced rate-limiting channels async concurrency backpressure
1use std::time::Duration;
2use tokio::sync::mpsc;
3use tokio::time::{interval, MissedTickBehavior};
4
5pub struct RateLimiter {
6 permits: mpsc::Sender<()>,
7}
8
9impl RateLimiter {
10 pub fn new(per_second: u32) -> Self {
11 let (tx, mut rx) = mpsc::channel::<()>(per_second as usize);
12 let (permits, mut requests) = mpsc::channel::<()>(1);
13
14 let period = Duration::from_secs_f64(1.0 / per_second as f64);
15 tokio::spawn(async move {
16 let mut ticker = interval(period);
17 ticker.set_missed_tick_behavior(MissedTickBehavior::Delay);
18 loop {
19 ticker.tick().await;
20 if requests.recv().await.is_none() {
21 break;
22 }
23 let _ = rx.recv().await;
24 }
25 });
26
27 drop(tx);
28 Self { permits }
29 }
30
31 pub async fn acquire(&self) {
32 let _ = self.permits.send(()).await;
33 }
34}
35
36impl Clone for RateLimiter {
37 fn clone(&self) -> Self {
38 Self { permits: self.permits.clone() }
39 }
40}
41
42pub async fn throttled_fetch(limiter: &RateLimiter, client: &reqwest::Client, url: &str) -> reqwest::Result<String> {
43 limiter.acquire().await;
44 client.get(url).send().await?.text().await
45}
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1Bounded channels turn producer/consumer pacing into natural backpressure without explicit locks.
  2. 2A single background task owning a timer keeps rate-limit state off the caller's hot path.
  3. 3Cloning a Sender shares one limiter across tasks while a dropped Sender signals graceful shutdown.
