python 61 lines · 7 steps

Building a circuit breaker in Python

A thread-safe decorator that stops calling a failing service until it has time to recover.

Explained by highlit
Advanced circuit-breaker resilience decorators concurrency state-machine
1import time
2import threading
3from enum import Enum
4from functools import wraps
5
6
7class State(Enum):
8 CLOSED = "closed"
9 OPEN = "open"
10 HALF_OPEN = "half_open"
11
12
13class CircuitOpenError(Exception):
14 pass
15
16
17class CircuitBreaker:
18 def __init__(self, failure_threshold=5, reset_timeout=30.0, expected=Exception):
19 self.failure_threshold = failure_threshold
20 self.reset_timeout = reset_timeout
21 self.expected = expected
22 self._state = State.CLOSED
23 self._failures = 0
24 self._opened_at = 0.0
25 self._lock = threading.Lock()
26
27 def _allow_request(self):
28 with self._lock:
29 if self._state is State.OPEN:
30 if time.monotonic() - self._opened_at >= self.reset_timeout:
31 self._state = State.HALF_OPEN
32 return True
33 return False
34 return True
35
36 def _on_success(self):
37 with self._lock:
38 self._failures = 0
39 self._state = State.CLOSED
40
41 def _on_failure(self):
42 with self._lock:
43 self._failures += 1
44 if self._state is State.HALF_OPEN or self._failures >= self.failure_threshold:
45 self._state = State.OPEN
46 self._opened_at = time.monotonic()
47
48 def __call__(self, func):
49 @wraps(func)
50 def wrapper(*args, **kwargs):
51 if not self._allow_request():
52 raise CircuitOpenError(f"{func.__name__} circuit is open")
53 try:
54 result = func(*args, **kwargs)
55 except self.expected:
56 self._on_failure()
57 raise
58 self._on_success()
59 return result
60
61 return wrapper
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1A circuit breaker trades a few fast failures for protecting a struggling downstream service from being hammered.
  2. 2The half-open state acts as a single probe that decides whether the circuit fully closes again or trips back open.
  3. 3Guarding shared counters and state transitions with a lock keeps the breaker correct under concurrent calls.
