How union-find with path compression works

A disjoint-set structure that tracks connected groups using union by rank and path compression for near-constant lookups.

Explained by highlit
Intermediate disjoint-set path-compression union-by-rank data-structures amortized-complexity
1public class UnionFind {
2 private final int[] parent;
3 private final int[] rank;
4 private int count;
5
6 public UnionFind(int n) {
7 parent = new int[n];
8 rank = new int[n];
9 count = n;
10 for (int i = 0; i < n; i++) {
11 parent[i] = i;
12 }
13 }
14
15 public int find(int x) {
16 while (parent[x] != x) {
17 parent[x] = parent[parent[x]]; // path compression
18 x = parent[x];
19 }
20 return x;
21 }
22
23 public boolean union(int a, int b) {
24 int rootA = find(a);
25 int rootB = find(b);
26 if (rootA == rootB) {
27 return false;
28 }
29 if (rank[rootA] < rank[rootB]) {
30 parent[rootA] = rootB;
31 } else if (rank[rootA] > rank[rootB]) {
32 parent[rootB] = rootA;
33 } else {
34 parent[rootB] = rootA;
35 rank[rootA]++;
36 }
37 count--;
38 return true;
39 }
40
41 public boolean connected(int a, int b) {
42 return find(a) == find(b);
43 }
44
45 public int count() {
46 return count;
47 }
48}
01 / 01
STEP 01

Walkthrough

Space play ←→ step click any line
Three takeaways
  1. 1Representing each set by a root element lets you test membership by comparing roots.
  2. 2Path compression and union by rank together keep operations nearly constant time.
  3. 3Tracking a count field gives you the number of distinct groups for free.
