Parsing and matching IPv4 CIDR ranges in Rust

An Ipv4Cidr type stores a network and mask as u32s so address membership is a single bitwise comparison.

Explained by highlit

Intermediate bitwise-operations parsing error-handling networking trait-implementation

1use std::net::Ipv4Addr;
2use std::str::FromStr;
3
4#[derive(Debug, Clone, Copy)]
5pub struct Ipv4Cidr {
6    network: u32,
7    mask: u32,
8}
9
10impl Ipv4Cidr {
11    pub fn contains(&self, addr: Ipv4Addr) -> bool {
12        (u32::from(addr) & self.mask) == self.network
13    }
14
15    pub fn broadcast(&self) -> Ipv4Addr {
16        Ipv4Addr::from(self.network | !self.mask)
17    }
18}
19
20impl FromStr for Ipv4Cidr {
21    type Err = String;
22
23    fn from_str(s: &str) -> Result<Self, Self::Err> {
24        let (addr, prefix) = s
25            .split_once('/')
26            .ok_or_else(|| format!("missing '/' in CIDR: {s}"))?;
27
28        let addr: Ipv4Addr = addr
29            .parse()
30            .map_err(|_| format!("invalid IPv4 address: {addr}"))?;
31
32        let prefix: u32 = prefix
33            .parse()
34            .map_err(|_| format!("invalid prefix length: {prefix}"))?;
35
36        if prefix > 32 {
37            return Err(format!("prefix out of range: /{prefix}"));
38        }
39
40        let mask = if prefix == 0 { 0 } else { u32::MAX << (32 - prefix) };
41
42        Ok(Ipv4Cidr {
43            network: u32::from(addr) & mask,
44            mask,
45        })
46    }
47}

01 / 01

STEP 01

Walkthrough

Space play ←→ step click any line

Three takeaways

1Representing IP addresses as u32 turns subnet membership into a cheap masking-and-compare operation.
2Building the netmask by shifting u32::MAX left by 32 minus the prefix cleanly separates network from host bits.
3Implementing FromStr with a String error and the ? operator gives ergonomic, descriptive parsing failures.
