Sliding-window rate limiting with Redis sorted sets

Use a Redis sorted set of timestamps to count requests in a rolling window and enforce a per-user limit.

Explained by highlit

Advanced rate-limiting redis sorted-sets sliding-window atomicity

1<?php
2
3namespace App\RateLimiting;
4
5use Predis\Client;
6
7final class SlidingWindowRateLimiter
8{
9    private const WINDOW_SECONDS = 3600;
10
11    public function __construct(
12        private readonly Client $redis,
13        private readonly int $maxRequests = 1000,
14    ) {
15    }
16
17    public function attempt(int $userId): RateLimitResult
18    {
19        $key = sprintf('ratelimit:user:%d', $userId);
20        $now = microtime(true);
21        $windowStart = $now - self::WINDOW_SECONDS;
22        $member = sprintf('%.6f:%s', $now, bin2hex(random_bytes(6)));
23
24        $responses = $this->redis->transaction(function ($tx) use ($key, $windowStart, $member, $now) {
25            $tx->zremrangebyscore($key, '-inf', $windowStart);
26            $tx->zadd($key, [$member => $now]);
27            $tx->zcard($key);
28            $tx->expire($key, self::WINDOW_SECONDS);
29        });
30
31        $count = (int) $responses[2];
32
33        if ($count > $this->maxRequests) {
34            $this->redis->zrem($key, $member);
35            $oldest = $this->redis->zrange($key, 0, 0, ['withscores' => true]);
36            $retryAfter = self::WINDOW_SECONDS;
37
38            if (!empty($oldest)) {
39                $oldestScore = (float) reset($oldest);
40                $retryAfter = (int) ceil($oldestScore + self::WINDOW_SECONDS - $now);
41            }
42
43            return new RateLimitResult(false, 0, max($retryAfter, 1));
44        }
45
46        return new RateLimitResult(true, $this->maxRequests - $count, 0);
47    }
48}

01 / 01

STEP 01

Walkthrough

Space play ←→ step click any line

Three takeaways

1A sorted set scored by timestamp turns rate limiting into a range-prune-then-count operation.
2Wrapping prune, add, count, and expire in one transaction keeps the count consistent under concurrency.
3Computing retry-after from the oldest surviving entry tells clients exactly when the window frees up.
