rust 48 lines · 7 steps

Per-IP rate limiting in Axum with tower-governor

Build an Axum router that throttles requests per client IP and prunes stale limiter state on a background loop.

Explained by highlit

Axum Intermediate rate-limiting middleware tower background-task shared-state

1use std::net::SocketAddr;
2use std::time::Duration;
3
4use axum::{routing::get, Json, Router};
5use serde_json::{json, Value};
6use tower_governor::governor::GovernorConfigBuilder;
7use tower_governor::key_extractor::SmartIpKeyExtractor;
8use tower_governor::GovernorLayer;
9
10pub fn api_router() -> Router {
11    let governor_conf = GovernorConfigBuilder::default()
12        .per_second(2)
13        .burst_size(5)
14        .key_extractor(SmartIpKeyExtractor)
15        .finish()
16        .expect("valid governor configuration");
17
18    let governor_conf = std::sync::Arc::new(governor_conf);
19    let limiter = governor_conf.limiter().clone();
20
21    tokio::spawn(async move {
22        let interval = Duration::from_secs(60);
23        loop {
24            tokio::time::sleep(interval).await;
25            tracing::debug!("rate limit storage size: {}", limiter.len());
26            limiter.retain_recent();
27        }
28    });
29
30    Router::new()
31        .route("/api/quotes", get(list_quotes))
32        .layer(GovernorLayer { config: governor_conf })
33}
34
35async fn list_quotes() -> Json<Value> {
36    Json(json!({
37        "quotes": [
38            { "author": "Hopper", "text": "Mind your own business is a poor motto." },
39            { "author": "Knuth", "text": "Premature optimization is the root of all evil." }
40        ]
41    }))
42}
43
44pub async fn serve(addr: SocketAddr) -> std::io::Result<()> {
45    let listener = tokio::net::TcpListener::bind(addr).await?;
46    let app = api_router().into_make_service_with_connect_info::<SocketAddr>();
47    axum::serve(listener, app).await
48}

01 / 01

STEP 01

Walkthrough

Space play ←→ step click any line

Three takeaways

1Rate limiting is added declaratively as a tower layer wrapping your routes, keeping handlers oblivious to it.
2Per-IP throttling needs the connection's address, which is why the service is built with connect-info.
3In-memory limiter state grows unbounded unless you periodically prune entries you no longer need.
